TLP351 (F)

Optical isolator

Optical isolator 3.75kV, 1-channel Gate Driver [DIP-8]

Inquire Now


TLP351 (F) Photocoupler, IGBT / MOSFET Gate-Drive, Toshiba.

Nom. number 9000594524
Weight g 1
Manufacturer Toshiba

The TOSHIBA TLP351 consists of a GaAℓAs light emitting diode and a integrated photodetector.

This unit is 8-lead DIP package.
TLP351 is suitable for gate driving circuit of IGBT or power MOS FET.
Especially TLP351 is capable of “direct” gate drive of lower Power

  • Peak output current: ±0.6 A (max)
  • Guaranteed performance over temperature: −40 to 100°C
  • Supply current: 2 mA (max)
  • Power supply voltage: 10 to 30 V
  • Threshold input current : IF = 5 mA (max)
  • Switching time (tpLH/tpHL) : 700 ns (max)
  • Common mode transient immunity: 10 kV/μs
  • Isolation voltage: 3750 Vrms
  • Option(D4) TLP351 (F)
  • VDE Approved : DIN EN60747-5-2
    Maximum Operating Insulation Voltage : 890VPK
    Highest Permissible Over Voltage : 4000VPK
