The TM4C123GH6PZT7 are built on the Cortex-M architecture and are designed for applications that require high performance and flexibility.
TM4C123GH6PZT7 is a microcontroller (MCU) family developed by Texas Instruments (TI). These MCUs are built on the Cortex-M architecture. Designed for applications requiring low power consumption, high performance and flexibility.
- Architecture: The Tiva C-series MCUs are base on the ARM Cortex-M4F core. These include a floating point unit (FPU) and a digital signal processing (DSP) engine. The Cortex-M4F core is know for its excellent performance. As well as its low power consumption and advanced instruction set.
- Peripheral Integration: Tiva C-series MCUs feature a wide range of integrated peripherals. Includes Analog-to-Digital Converter (ADC), Digital-to-Analog Converter (DAC), UART, I2C interface. And SPI interface, USB interface, Ethernet MAC ect. This high level of integration reduces the need for external components. Simplifies system design and reduces cost.
- Memory: Tiva C-Series MCUs have large on-chip memory. Includes Flash for program storage and SRAM for data storage. The MCU also has a memory protection unit (MPU). Provides hardware-based memory protection and security.
- Power Management: Tiva C-series MCUs have extensive power management features. Includes multiple low-power modes, deep-sleep, and hibernation. These features enable the MCUs to operate on very low power and extend battery life.
- Development Tools: TI offers a comprehensive set of development tools for the Tiva C-series MCUs. Includes a free Integrated Development Environment (IDE), Software Development Kit (SDK) called Code Composer Studio (CCS). and a range of evaluation and development boards.
Q: What is the difference between Tiva C Series and Stellaris LM4F series?
A: The Tiva C series is the successor to the Stellaris LM4F series. There are several improvements over its predecessor. Tiva C-Series MCUs feature faster processors and more memory. As well as better power management features and more integrated peripherals. In addition, the Tiva C Series is fully supported by TI’s new development tools and software. The Stellaris LM4F series has been phase out.
Q: What is the maximum clock frequency of the Tiva C Series?
A: The maximum clock frequency of the Tiva C Series varies depending on the specific MCU. The highest clock frequency available is 120 MHz. Some of the more advanced models in the series offer this frequency.
Q: What development tools are available for programming the Tiva C Series?
A: TI offers a range of development tools for programming the Tiva C Series. Includes free Code Composer Studio IDE, TivaWare Software Development Kit (SDK). and a range of evaluation and development boards.
Q: What programming languages are supporte by the Tiva C Series?
A: The Tiva C Series supports several programming languages, including C and C++. In addition, TI offers a tool for using TI’s proprietary programming language called TI-RTOS. Libraries and examples to program the MCU with.
Q: What is the power consumption of the Tiva C Series?
A: The power consumption of the Tiva C Series varies depending on the specific MCU and the operating conditions. However, MCUs are design for low power consumption. They provide various power management functions. Includes various low-power modes, deep-sleep, and hibernation.
